INVESTIGASI FAKTOR USIA MODALITAS MRI 1.5 TESLA TERHADAP SIGNAL TO NOISE RATIO
DOI:
https://doi.org/10.38165/jk.v16i2.459Keywords:
DWI, FLAIR, T2* GRE, Signal to Noise Ratio (SNR), 1.5 Tesla MRI ModalitiesAbstract
Changes in signal-to-noise ratio (SNR) may be influenced by the installation age of MRI systems exceeding 10 years, as well as increased usage frequency, which can contribute to a decline in system performance. This study investigated the effect of MRI installation age on SNR in two different brands of 1.5 Tesla MRI systems. This research employed an experimental method by measuring SNR values using an MRI phantom filled with 1000 cc of water. Image acquisition was performed using FLAIR, DWI, and T2*GRE sequences. SNR measurements were conducted using ImageJ software with a consistent region of interest (ROI) diameter of 5 mm applied to all images. Statistical analysis was performed to assess differences in mean SNR values between the two 1.5 Tesla MRI systems using an independent samples t-test with a significance level of 0.05. The results showed that the SNR value for the FLAIR sequence was 102.8 for brand A and 65.8 for brand B, with a p-value of 0.00. For the DWI sequence, the SNR value was 63.4 for brand A and 54.3 for brand B, with a p-value of 0.04. For the T2*GRE sequence, the SNR value was 107.1 for brand A and 45.2 for brand B, with a p-value of 0.00. Differences in SNR values were associated with variations in acquisition parameters such as TR, TE, NEX, and bandwidth, differences in the number of head coil channels, as well as differences in production year and duration of MRI system utilization. Therefore, standardization of acquisition parameters, routine technical evaluation of MRI systems, and detailed analysis of DICOM metadata are recommended in future studies to achieve more objective and accurate comparisons of MRI image quality.
Abstrak: Perubahan nilai signal to noise ratio (SNR) disebabkan faktor usia instalasi modalitas MRI yang sudah mencapai lebih dari 10 tahun, serta frekuensi penggunaan yang semakin tinggi yang dapat menyebabkan penurunan kinerja modalitas. Penelitian ini melakukan investigasi faktor usia instalasi modalitas MRI terhadap SNR pada dua merek modalitas MRI dengan kekuatan medan magnet 1.5 Tesla. Metode penelitian ini adalah eksperimen dengan melakukan pengukuran nilai SNR pada dua modalitas MRI menggunakan pantom MRI yang berisi air dengan volume 1000 cc pada penggunaan sequence FLAIR, DWI dan T2*GRE. Pengukuran SNR menggunakan Image-J dengan mempertimbangkan ukuran regoin of interest (ROI) berdiameter 5 mm sama pada semua citra. Kemudian dilakukan uji statistik untuk mengetahui adakah perbedaan nilai rata-rata SNR pada kedua modalitas MRI 1.5 Tesla dengan uji Independent t-test dengan nilai p-value 0.05. Hasil penelitian untuk nilai SNR pada sequence FLAIR untuk merek A 102.8, sedang merek B 65.8 dengan hasil p-value 0.00. Nilai SNR Pada sequence DWI untuk merek A 63.4, sedangkan merek B 54.3 dengan hasil p-value 0.04. Nilai SNR Pada sequence T2*GRE untuk merek A 107.1, sedangkan merek B 45.2 dengan hasil p-value 0.00. Perbedaan nilai SNR tersebut berkaitan dengan variasi parameter akuisisi seperti TR, TE, NEX, dan bandwidth, perbedaan jumlah channel head coil, serta perbedaan tahun produksi dan usia pemanfaatan perangkat MRI. Oleh karena itu, perlunya standarisasi parameter akuisisi, evaluasi teknis perangkat MRI secara berkala, serta analisis metadata DICOM pada penelitian selanjutnya guna memperoleh perbandingan kualitas citra MRI yang lebih objektif dan akurat.
References
Cahyaningrum, D. (2020). et al , 2004). Valuasi Penggunaan Sequence T1, T2, Dan Susceptibility Weighted Imaging (SWI) Pada Kasus Perdarahan Otak Kronis, 1–5.
Dietrich, O., Raya, J. G., Reeder, S. B., Reiser, M. F., & Schoenberg, S. O. (2007). Measurement of signal-to-noise ratios in MR images: Influence of multichannel coils, parallel imaging, and reconstruction filters. Journal of Magnetic Resonance Imaging, 26(2), 375–385. doi: 10.1002/jmri.20969
European Society of Radiology (ESR). (2014). Renewal of radiological equipment. Insights into Imaging, 5(5), 543–546. doi: 10.1007/s13244-014-0345-1
Horowitz, A. L. (n.d.). FHB (Radiology golden books) (Third edit).
Maulida, N., Susanto, E., & Murniati, E. (2019). Prosedur Pemeriksaan Magnetic Resonance Imaging (Mri) Brain Perfusi Dengan Metode Arterial Spin Labeling (Asl) Pada Pasien Tumor. JRI (Jurnal Radiografer Indonesia), 2(1), 48–58. doi: 10.55451/jri.v2i1.33
Mehan, W. A., González, R. G., Buchbinder, B. R., Chen, J. W., Copen, W. A., Gupta, R., Hirsch, J. A., Hunter, G. J., Hunter, S., Johnson, J. M., Kelly, H. R., Larvie, M., Lev, M. H., Pomerantz, S. R., Rapalino, O., Rincon, S., Romero, J. M., Schaefer, P. W., & Shah, V. (2014). Optimal brain MRI protocol for new neurological complaint. PLoS ONE, 9(10). doi: 10.1371/journal.pone.0110803
Muhammed, E. (2014). MR Physics, Patient Positioning and Protocols. In Paper Knowledge . Toward a Media History of Documents.
Muzamil, A. (2019). Optimalisasi citra axial sequence t2 GRE dengan variasi bandwidth dan TE pada MRI shoulder untuk mengurangi susceptibility artifacts dan chemical shift. Jurnal Of Health, 5, 40–49.
Rais, M. R., & Darmini, D. (2018). Effect of Receive Bandwidth’S Variation To Signal To Noise Ratio (Snr) and Contrast To Noise Ratio (Cnr) on Mri Examination of Cervical With T2 Weighted Fast Spin Echo Sequenc Hernia Nuckleus Pulposus (Hnp) Case. Jurnal Imejing Diagnostik (JImeD), 4(2), 98. doi: 10.31983/jimed.v4i2.4009
Rochmayanti, D., Widodo, T. S., & Soesanti, I. (2013). Analisis Perubahan Parameter Number of Signals Averaged ( NSA ) Terhadap Peningkatan SNR dan Waktu Pencitraan pada MRI. Jnteti, 2(4), 37–45.
Susanto, F., Santoso, G., & Abimanyu, B. (2018). Perbedaan Pembobotan T2 Turbo Spin Echo (Tse) Mri Brain Potongan Axial Antara Penggunaan Sensitivity Encoding (Sense) Dengan Tanpa Sense : Evaluasi Pada Signal To Noise Ratio (Snr) Dan Scan Time. JRI (Jurnal Radiografer Indonesia), 1(1), 30–36. doi: 10.55451/jri.v1i1.8
Tanjung, A., Prastowo, A., & Setiabudi, W. (2013). Korelasi Nilai Time Repetition (Tr) Dan Time Echo (Te) Terhadap Signal To Noise Ratio (Snr) Pada Citra Mri. Berkala Fisika, 16(4), 103–110.
Wardlaw, J., Brindle, W., Casado, A., Shuler, K., Henderson, M., Thomas, B., Macfarlane, J., Maniega, S., Lymer, K., Morris, Z., Pernet, C., Nailon, W., Ahearn, T., Mumuni, A. N., Mugruza, C., Mclean, J., Chakirova, G., Tao, Y. T., Simpson, J., … Weir, N. (2012). A systematic review of the utility of 1 . 5 versus 3 Tesla magnetic resonance brain imaging in clinical practice and research. June. doi: 10.1007/s00330-012-2500-8
Wedayanti, L., Sudiyono, & Baskoro, N. (2019). Uji Quality Control Pesawat Magnetic Resonance Imaging Siemens Magnetom Concerto 0,2 Tesla di Instalasi Radiologi RSUD Dr Kanujoso Djatiwibowo Balikpapan. Jurnal Imejing Diagnostik (JImeD), 5, 74.
Westbrook, C., Roth, C., & Talbot, J. (2011). MRI in Practice Fourth Edition. In Journal of Chemical Information and Modeling (4th ed., Vol. 53, Issue 9).
Wood, D. A., Kafiabadi, S., Busaidi, A. Al, Guilhem, E., Montvila, A., Lynch, J., Townend, M., Agarwal, S., Mazumder, A., Barker, G. J., Ourselin, S., Cole, J. H., & Booth, T. C. (2022). Accurate brain?age models for routine clinical MRI examinations. NeuroImage, 249(November 2021). doi: 10.1016/j.neuroimage.2022.118871
